The electric forklift side shifter has an excellent design and a wide field of view. It does not require welding or drilling for installation and can be used by simply hanging it on the fork frame of the forklift.
The fork is the most commonly used pickup device for forklifts, which is why the forklift is named so. A forklift is equipped with two forks shaped like the letter L. The horizontal section of the fork is the working part for placing the goods and the ve
The forklift gantry is the inner and outer door frame of the forklift lifting mechanism. Its stability and load‑bearing capacity are crucial to the working efficiency and operational safety of the forklift
Solid tires are an industrial tire suitable for vehicles traveling under harsh conditions such as low speed and high load. They are significantly superior to pneumatic tires in terms of safety, durability, and economy, and are widely used in various indus
The compact body design and smooth cargo‑sensing steering system have a small turning radius and can operate in narrow storage lanes.
The system has high efficiency, complete protection functions, built‑in speed sensor and temperature sensor, high reliability and long service life.
New concept design, no need to hang the battery out from the gap at the top of the roof guard, and the battery can be quickly replaced.
Ergonomically designed small‑diameter steering wheel with adjustable tilt makes it easy for the driver to operate.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Load capacity | 2000kg |
| Length (without forks) | 3270mm |
| width | 1100mm |
| Height (roof guard) | 1100mm |
| Lifting height | 3000mm(customizable) |
| No‑load maximum running speed (adjustable) | 12km/h |
| Full load maximum operating speed (adjustable) | 10km/h |
| Front Wheel Specifications | 18X7‑10 |
| rear wheel specification | 15X4.5‑8 |
| vehicle color | custom color |
| Wheel | 3 |
