The forged fork is made of high‑strength material, which is forged at high temperature and precisely processed to have extremely high strength and durability. This material and process ensure that the forged fork can withstand heavy loads and frequent use
The design of the foot pedal makes the operator more comfortable when operating the stacker, reduces fatigue caused by standing for a long time, and improves the reliability and comfort of operation
The stacker gantry is the inner and outer door frame of the lifting mechanism. Its stability and load‑bearing capacity are crucial to the working efficiency and operating safety of the forklift
The mast can be moved forward and retracted by 45cm. When the mast is retracted, the center of gravity of the goods is inward, and it is safer to carry and pile up when forklifting. The mast moves forward.
No support legs for both single and double sided pallets.
The mast can be tilted forward and backward by 5°, the mast is tilted forward, and the front section of the fork is close to the ground to facilitate forking and picking up goods. The door frame is tilted forward, and the goods are stable and not easy to
Inscription‑plated piston rod, imported seals to prevent oil leakage.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Load capacity | 1000‑2000kg |
| Wheelbase | / |
| Overall Length | 3200mm |
| Overall Width | 1050mm |
| Lift Height | 1600‑6000mm |
| Lowered mast height | 1600/2300 |
| Fork Dimension | 1070(customizable) |
| Ground Clearance at center of wheelbase (Min) | 65mm |
| Turning Radius | 2200mm |
| Type of operation | Stand‑up |
