The forged fork is made of high‑strength material, which is forged at high temperature and precisely processed to have extremely high strength and durability. This material and process ensure that the forged fork can withstand heavy loads and frequent use
Due to their excellent grip and traction, off‑road tires enable electric stackers to operate efficiently on a variety of terrains, including uneven ground, slopes, etc., improving the adaptability and efficiency of operations
The stable chassis can effectively lower the center of gravity of the stacker, thereby enhancing its stability. The low center of gravity design makes the stacker more stable during operation and reduces the risk of overturning
The intelligent operating handle can significantly improve work efficiency and better adapt to complex and changing working environments and task requirements.
Large tires, with larger torque drive wheels, suitable for a variety of ground
It is more convenient to use the two operation modes of walking/standing driving
Brand electronically controlled pumping station with higher stability.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Load capacity | 1500‑3000kg |
| Wheelbase | / |
| Overall Length | 1720mm |
| Overall Width | 1574mm |
| Lift Height | 1600‑3000mm |
| Lowered mast height | 2080/2080mm |
| Fork Dimension | 1070*100*35mm |
| Ground Clearance at center of wheelbase (Min) | / |
| Turning Radius | 1355mm |
| Type of operation | walkie |
