The advantages of electric stacker batteries mainly include high energy density, long battery life, intelligent power‑off protection and efficient energy utilization.
The forged fork is made of high‑strength material, which is forged at high temperature and precisely processed to have extremely high strength and durability. This material and process ensure that the forged fork can withstand heavy loads and frequent use.
The design of the foot pedal makes the operator more comfortable when operating the stacker, reduces fatigue caused by standing for a long time, and improves the reliability and comfort of operation.
The intelligent operating handle can significantly improve work efficiency and better adapt to complex and changing working environments and task requirements.
The AC brushless drive motor is maintenance‑free and cost saving;
CURTIS AC control system, accurate control, higher efficiency;
Equipped with electronic steering, so that steering more effort, even in small space can be comfortable and free steering, reduce fatigue strength, improve efficiency;
Imported integrated control system,smooth travel control, superior speed regulation performance;
undulation of the road surface to ensure that the driving wheel is always in contact with the road surfac, ground contact, not easy to skid.
The electromagnetic clutch has multiple braking functions,such as power‑off breaking, regenerative braking, and reverse braking ,making it safer and more comfortable;
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Load capacity | 1600kg |
| Wheelbase | 1440mm |
| Overall Length | 2335/2750mm |
| Overall Width | 880/1030mm |
| Lift Height | 3000mm |
| Lowered mast height | 2040mm |
| Fork Dimension | 1070×100×40 |
| Ground Clearance at center of wheelbase (Min) | 55mm |
| Turning Radius | 1710/2145mm |
| Type of operation | Stand‑up |
