The operating console includes important components such as operating levers, instrument panels and other core parts, which are used to control the forklift and display the vehicle's status and performance parameters and other core functions.
A compression ignition internal combustion engine that uses diesel as fuel is also called a diesel engine. Its working principle is to generate high temperature through compressed air to ignite atomized diesel, converting heat energy into mechanical energy.
The fork is the most commonly used pickup device for forklifts, which is why the forklift is named so. A forklift is equipped with two forks shaped like the letter L. The horizontal section of the fork is the working part for placing the goods.
It has good shock absorption effect, can reduce vibration and impact during driving, and improve driving comfort; it performs well under working conditions and is suitable for most working environments.
Wide‑view mast design makes the driver’s field of view wider
High air intake system design keeps the engine away from dust, effectively exerts engine performance and improves service life
Reliable LCD digital special instrument and friendly human‑machine interface make it easy for the driver to accurately control the vehicle status
The smaller front overhang design effectively reduces the front axle load under full load and greatly increases the life of the front tires and drive axle.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Load Capacity | 5000‑7000kg |
| Max Lifting Height | 6000mm |
| Load Center Distance | 600mm |
| Overall Length | 4690‑4810mm |
| Over Width | 1970mm |
| Over Height | 2500mm |
| Mast Forward Tilt Angle | 6° |
| Mast Tilted Backward | 12° |
| Forklift Weight | 8400‑9600kg |
| Min Turning Radius | 2710‑2900mm |
| Max Working Speed | 22/29‑24/29km/h |
