The joystick layout is reasonable and the operation is simple and convenient, which provides convenient operation for construction workers and can reduce the workload of operators.
The roof of the mini excavator can not only provide shade and protection, but can also be disassembled and installed as needed to adapt to different working environments and operating requirements. This design allows the equipment to perform at its best.
Mini excavator engines are generally versatile and can be adapted to different working conditions.
The main function of the mini excavator travel motor is to convert hydraulic energy into mechanical energy to drive the excavator forward, backward and turn.
Standard display instrument panel, foot‑operated crushing control system.
The side swing of the big arm can be installed, and the left and right swing arms are 60 degrees each.
The chassis can be extended and extended, especially for small spaces, with a telescopic range of 84cm‑104cm.
The cab and heater can be installed, so there is no trouble in all‑weather operation.
Optional hydraulic pilot operation, can be installed with high and low speed walking 1.8‑3.7km/h
Standard fuel engine, optional 380V/220V/110V motor or lithium battery.
One more working pipeline can be added, and two actions of rotation and grabbing can be realized at the same time.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Vehicle weight | 1200kg |
| Machine size | 2870*1000*2285mm |
| Engine | Koop/Changchai 192 |
| Engine power | 12hp |
| Maximum Digging Radius | 2500mm |
| Maximum Digging Depth | 1650m |
| Maximum Digging Height | 2490mm |
| Maximum dump height | 1745mm |
| Minimum turning radius | 1605mm |
| Chassis width | 1000mm |
