The chassis design of the mini excavator takes operational safety into consideration. The full‑view, fully open design allows the driver to clearly see the surrounding environment. It is also equipped with a seat safety bar to ensure the safety of the mac
Mini excavator engines are generally versatile and can be adapted to different working conditions.
The ground contact pressure of the steel track chassis is only 1/3 of that of wheeled vehicles. Combined with the bionic track pattern design, it can travel stably in extreme environments such as muddy swamps, snowy steep slopes, and gravel deserts avoid
The mini excavator bucket has a compact design and is suitable for working in narrow spaces, such as urban alleys, indoor construction sites or orchard nurseries and other restricted environments
Domestic famous brand engine, strong power, meets the requirements of efficient operation.
Precise matching design and advanced energy‑saving control make the machine consume less fuel.
Low emission, meet the national IV standard.
The adoption of new cooling fan and large muffler makes the noise of the machine lower;
Adopt advanced turbocharging technology to enhance the plateau adaptability of the machine;
The unique funnel‑shaped fan cover greatly improves the air intake of the engine and the cooling capacity of the system, ensuring continuous and efficient operation of the machine.
Integrate the latest research results, reduce energy consumption, improve design, and respond faster.
Double‑pump confluence technology: increase the flow of the main valve to supply the oil cylinders of the boom, stick and bucket, and improve the working speed.Rugged and high reliability
Improving the design of the cross‑sectional shape of the track frame, reducing soil accumulation, making the carrier sprocket less prone to wear and improving the durability of the machine.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Vehicle weight | 6000kg |
| Machine size | 5940*1880*2570mm |
| Engine | Kubota V2607 |
| Engine power | 58hp |
| Maximum Digging Radius | 6128mm |
| Maximum Digging Depth | 3808mm |
| Maximum Digging Height | 5499mm |
| Maximum dump height | 3845mm |
| Minimum turning radius | 2607mm |
| Chassis width | 1880mm |
